Digital Microprocessor Power Factor Controller
Electrotek AHF Series – Active Harmonic Filters
Filtered Automatic PFC Unit
Assembly Specification
Complete with: |
HRC fusing (2 required for non-grounded systems, 3 required for grounded systems) |
Available Options
Options |
blown fuse indicators NEMA 3R galvanized terminal box |
Capacitor Specifications
Manufactured by |
Vishay Electronic GmbH (Roederstein), Germany |
Voltage Ratings |
2400V, 4160V, 4800V |
Maximum kVAr per 3 phase casing (60 Hz) |
500 kVAr @ 2400V 500 kVAr @ 4160V 500 kVAr @ 4800V |
Specifications |
CSA CAN3-C155-M84 (1986), CSA C22.2 No.190, IEC 60871-1, VDE 560/4, AS 2897, ANSI IEEE Std.18, NEMA CP-1, BS 1650 |
Insulation (wet and dry options) |
non-PCB, natural oil impregnant |
Ambient Temperature |
-35°C to +45°C |
Loading Capacity |
1.10 times rated voltage 1.80 times rated current |
Frequency Ratings |
60 Hz |
Capacitor Casing |
stainless steel |
Losses |
≤ 0.05 Watts per kVAr |
Discharge Resistors |
50V or less in five minutes after disconnection of supply voltage |
Dielectric |
polypropylene film |
Safety Features |
self-healing |
Special Applications |
designed for use in harmonic filters |
